I've a PhD in Physics, from the University of Warwick. My thesis, submitted in 2000, was on ion scattering spectroscopy of III-V semiconductor surfaces. These kinds of semiconductors are used in optoelectronics, like the lasers in Blu-ray players, infrared detectors, and solar cells. All this clever tech relies on carefully manufactured crystal structures, like building layers of Lego on a nano-scale. For my doctorate, I explored how atoms arrange themselves in the top few layers of atoms on crystals of these semiconductors.

Semiconductor surfaces 101

Deep inside a crystal (in the bulk), each atom is completely surrounded by other atoms. Like someone squashed in the middle of a festival crowd, each atom experiences similar forces acting from all sides. Because every atom experiences similar forces, they all behave the same way, and that's why they tend to line up to form a nearly perfect regular crystal structure, like the ball-and-stick models you probably saw in science class.

However, atoms at the surface behave differently from those deep within a crystal. At the surface, the atoms don't have forces acting from above. Without the balancing forces from atoms above them, the surface atoms naturally tend to re-organize themselves or reconstruct. They tend to lie in regular patterns on top of the surface, but usually not packed the same way as below. Imagine crowd-surfers at our festival, who all stretch out, linking hands. Understanding these reconstructions is important for nanotechnology. Controlling atomic structure is how you build on a tiny scale.

It can be hard to see individual atoms without interfering with their position. In my PhD, I used techniques which only gave an indirect picture of the surface's structure. I had to infer the structure — like trying to tell what someone looks like if you can only see their shadow. I created computer models of what I thought the surface structure might be, ran some simulations, and compared to the real experiment to see whether my models were a good fit.

These techniques require an ultra-high vacuum (UHV) of around one millionth of a millionth of the pressure in the atmosphere (give or take) to keep the surfaces free from contamination, and to avoid pesky air molecules getting in the way of measurements.

I used some well-established techniques, such as LEED and AES. But most of my work was performed using ion-scattering spectroscopy (ISS), where I fired helium ions at a surface, and measured the direction and quantity of what bounced off. I used equipment at two laboratories. One was the low energy CAICISS system (pronounced kye-siss /kaɪ-sɪs/), of the Surface Physics group in the Department of Physics at the University of Warwick. The other was the medium energy MEIS facility (yes, it's pronounced mice), formerly at Daresbury Laboratory and now sited at the University of Huddersfield. My work was funded by a studentship from the EPSRC.

The materials were prepared in vacuo using atomic hydrogen cleaning (AHC). This removes carbon contamination - organic stuff from the atmosphere like fingerprints and breath - by a combination of chemical reaction and physically knocking off the crud. The latter is called sputtering, which I always think is delightfully onomatopoeic.

Anyway, I used AHC to prepare clean, reconstructed surfaces by firing a beam of hydrogen ions at crystals of different semiconductors at different temperatures. Using ISS and LEED, I identified that by changing the cleaning conditions, I could create several distinct reconstructions. I identified some novel reconstructions, and proposed some model structures that might cause them.

The result

I was admitted to the degree of Doctor of Philosophy in Physics, of the University of Warwick, on 12 January 2001. My doctoral thesis is available for download in PDF format (screen-resolution, 3.42M). If you read it, please let me know! Since then, I have gained the professional qualification of Chartered Scientist, and membership of the Institute of Physics. (I used to be a Chartered Physicist, but having moved away from the field, it no longer seemed appropriate) So, these days, I am formally Dr Nick Kaijaks, CSci MInstP. Yay me!
